MiniRedone Series
MiniElephant MiniRedone-IV
Tall backrest design : 1250mm for full back support
The MiniRedone-IV features the tallest backrest in the series at 1250mm, providing comprehensive back support for users who require full spinal alignment. Built on the same one-piece magnesium alloy die-cast frame with self-developed hub motors and LiFePO₄ battery, despite its taller profile it maintains a lightweight 43KG construction and folds compactly for transport.
Key Difference
Request QuotationTall backrest (1250mm) at 43KG
Technical Specifications
| Net Weight | 43 KG |
| Max Load | 150 KG |
| Range | ≈30 KM |
| Max Speed | ≤6 KM/H |
| Battery | 16Ah LiFePO₄ Lithium Battery |
| Motor | Dual 350W Self-developed Hub Motors |
| Frame Material | Magnesium Alloy (one-piece die-cast) |
| Folded Dimensions | L830×W675×H1250 mm |
| Seat Dimensions | L1005×W675×H1250 mm |
| Back Height | Extra tall (1250mm) |
| Charging Time | 4-6 hours |
Key Features
- Extra tall 1250mm backrest for full back support
- Lightweight 43KG design
- One-piece magnesium alloy die-cast frame — no welding, superior strength
- Dual 350W self-developed hub motors : whisper-quiet, 85% efficiency
- Zero rolling resistance when free-wheeling — easy to push without power
- 16Ah LiFePO₄ battery : 30km range, 2000+ charge cycles
- Modular seat system compatible with multiple seat styles
- Pneumatic shock-absorbing front fork with gas spring
- Hand/foot dual brake system
- Foldable with tall backrest
- Anti-tip wheels tested for 15° slope safety
