MiniRedone Series
MiniElephant MiniRedone-II
Lighter design at just 42KG : ultimate portability
The MiniRedone-II is our lightweight champion at just 42KG. Built on the same one-piece magnesium alloy die-cast frame with self-developed hub motors and LiFePO₄ battery, we've shed significant weight through advanced engineering without compromising strength or performance. Perfect for users who frequently transport their wheelchair or have limited storage space.
Key Difference
Request QuotationLighter weight at 42KG
Technical Specifications
| Net Weight | 42 KG |
| Max Load | 150 KG |
| Range | ≈30 KM |
| Max Speed | ≤6 KM/H |
| Battery | 16Ah LiFePO₄ Lithium Battery |
| Motor | Dual 350W Self-developed Hub Motors |
| Frame Material | Magnesium Alloy (one-piece die-cast) |
| Folded Dimensions | L830×W675×H945 mm |
| Seat Dimensions | L1005×W675×H945 mm |
| Charging Time | 4-6 hours |
Key Features
- Ultra-light 42KG frame : easiest to lift and transport
- One-piece magnesium alloy die-cast frame — no welding, superior strength
- Dual 350W self-developed hub motors : whisper-quiet, 85% efficiency
- Zero rolling resistance when free-wheeling — easy to push without power
- 16Ah LiFePO₄ battery : 30km range, 2000+ charge cycles
- Modular seat system compatible with multiple seat styles
- Pneumatic shock-absorbing front fork with gas spring
- Hand/foot dual brake system
- Compact folding design
- Anti-tip wheels tested for 15° slope safety
